BOUNTY: Auxiliary ketch and tender, Design #58
plans set
SHIPS PLANSHerreshoff, L. Francis; Britt Brothers; Luke, Paul E.
1933-11-02; 1966-03-03
22 sheets of plans for 57.5 ft. auxiliary ketch, BOUNTY (built 1934) and 11.08 ft. tender to BOUNTY (built 1934), design #58 by L. Francis Herreshoff. Dates on plans range from 11-02-1933 to 03-03-1966. 11 sheets are duplicates.
Ships plans available for Cat. #38.1:
Sheet # Date View; Scale
1 1934 Sail plan; 3/8" = 1
2 11/14/1933 Cabin plan; 1/2" = 1
3 11/02/1933 Ratsey & Lapthorn sail plan; 3/8" = 1'
4 11/1933 Detail of cabin table; 1 1/2" = 1’ and full size;
5 11/15/1933 Gasoline & water tanks; 1 1/2" = 1';
6 not dated Piping plan; 1/2" = 1';
7 11/15/1933 Detail of main skylight; 3" = 1';
8 not dated Flag staff; 1" = 1';
14 05/28/1964 Revised layout cabin plan
15 1934 Revised sail plan
SP.38.1
Mystic Seaport, Daniel S. Gregory Ships Plans Library, L. Francis Herreshoff Collection
