Cross section of 30 square meter boom

boom cross section

SHIP & BOAT PIECES
Tamm, Bror
wood
overall: 4 x 2-1/8 x 0-1/2 in.

Boom cross section; cross section of 30 square meter, possibly designed by L. Francis Herreshoff; section is rectangular, made up of two pieces of wood glued together, keyhole cutout at top for sail track; sticker on back, white with red border; handwritten on sticker "253/ B". Similar to 2002.94.9.


2002.94.10
