Cross section of spar from MANDOO II

spar cross section

PATTERNS & MOLDS
Herreshoff Manufacturing Company
USA, RI, Bristol
1936
wood
overall: 0-5/8 x 9-1/8 x 12-1/4 in.

Spar cross section; flat cross section of spar, probably main mast, from MANDOO II (built 1936), made up of 9 pieces of wood glued together, piece of plywood glued to back, piece of brown paper glued to plywood; handwritten on back of plywood "246/ C". MANDOO II was designed by John G. Alden and built by Herreshoff Manufacturing Company, unclear if Bror Tamm had any connection with its construction. Related to 2002.94.72.

2002.94.73
